Laboratory Taps

Suspended turret with 45° valve for compressed air with quick release coupling

€221.50 ex. VAT

Categories: Tags: , , , , , SKU: 2530 160 1021-52B

Description

BROEN’s Suspended Turret with 45° Valve for Compressed Air optimizes efficiency and flexibility in laboratory environments. Designed for secure connections, it features a quick-release coupling, enabling fast and reliable operation.

Moreover, the 45° valve ensures smooth control and effortless usability, making it ideal for a variety of applications. Additionally, its high-quality construction enhances durability and guarantees long-lasting performance.

To further withstand demanding conditions, the BROEN-LAB POLYCOAT powder coating offers superior resistance against chemicals, UV light, and heat. Furthermore, with a maximum working pressure of 7 bar and a temperature range from 5°C to 60°C, this fitting meets the rigorous standards required in modern laboratories.

Additional information

Model

2530 160 1021-52B, 2530 160 1022-52B, 2530 160 1023-52B, 2530 160 1024-52B, 2530 160 1025-52B, 2530 160 1026-52B, 2530 160 1027-52B

Media type

Compressed Air, Oxygen, Nitrogen, Carbon Dioxide, Argon, Helium, Dinitorgen monoxide

Mounting

Suspended turret fittings

Handle

Metal BROEN-LAB POLYCOAT powder coated with media indication according to EN13792

Head nozzle

quick release coupling (hexagon coded)

Headwork

Needle, High flow

Opening/closing function

6 x 360?, 1.5 x 360

Max. working pressure

16 bar / 232 psi, 1 bar to 16 bar / -14.5 psi to 232 psi

Allowable test pressure after installation

1.5 x max working pressure without function of the valve

Metals with media contact

Brass

Plastics with media contact

PVDF SPX (hose)

Sealing with media contact

FKM

Lubricant with media contact

Perfluoropolyether based

View Specification

Download
